7 Inch Clip on AHD Mirror Monitor
Name:7 Inch Clip on AHD Mirror Monitor
Model No.:FA-778AHD
Screen Size:7 Inch Clip on AHD Mirror Monitor
Aspect Ratio:16: 9
Video Input:2 Way AHD Input
Back Light luminance:500cd/m2
System:PAL& NTSC
Remote Control:yes
Power Supply:Power Supply: Input Power:DC12V-36V, Output Power: DC12V
Product Size:260x106x3mm
Connector:RCA or 4-PIN
Mounting:Clip On Original Mirror
Warranty:1 year

Key Features:

7 Inch Clip on AHD Mirror Monitor

FA-778AHD Specifications:

7 Inch AHD Vehicle Mounted Mirror Monitor
Universal Size Clips onto Existing Mirrors
Aspect ratio: 16:9 Wide Screen
High Resolution:1024xR.G.Bx600
Back Light luminance: 500cd/m2
2 Way AHD Video Input,single image display, support 720P@25/30, 720P@50/60, 1080P@25/30
Power Supply: Input Power:DC12V-36V, Output Power: DC12V
System: NTSC & PAL (automatically)
OSD Language:English,Deutsch,French,Spanish,Portugal,Italian,Dutch,Simplify Chinese
Automatically switch to V2 when reversing
Touch Buttons Control
Built-in SD/USB(Optional)
Material: ABS
View Angle: Hor. L(180) R(180)  Ver. UP(180) DOWN(180)
Storage temperature: -30°C ~80°C
Working temperature:-20°C ~ 70°C
Power consumption: 5W
Size: 260x106x3mm
Connector: 4-Pin Connector/RCA Connector optional

Hits: 【Print】
Pre:5 inch AHD 1080P Car Monitor with IPS Screen     Next:Dual Lens AHD Reversing Camera

Packaging & Delivery

Packaging Details

Giftbox or White box Package

Delivery Time

Sample in 3-5 days, normal order completed in 2-3 weeks after receiving payment copy.
