5 inch IP69 waterproof monitor

Model No.:FA-505
Screen Size:5 Inch Waterproof Monitor with 2 AV Input
Aspect Ratio:16:9
Resolution:640xR.G.Bx480
Video Input:2 Way Input
Audio Input:No
System:PAL& NTSC
Remote Control:Yes
Power Supply:DC12V-32V
Bracket:U Shape Braket
Trigger:2Ways
Waterproof Grade:IP69
Warranty:1 Year

5 inch IP69 waterproof monitor with 2 video input

FA-505 Specifications:

Screen: 5 inch IP69 waterproof monitor

Sunshade outline design

[4:3 ] wide screen display

Resolution: 640xRGBx480

Contrast Ratio: 500:1

Brightness: 400cd/m2

Compatible system: NTSC & PAL (automatically)

View angle: Hor. L(70) R(70) Ver. UP(50) DOWN(70)

Power requirement: DC12V-32V

Power consumption: 8.64W

Working temperature: -10 to +65

Reverse Guideline: Yes

Mirror/Normal Switch: yes

2 Reverse Triggers: automatically

Dustproof & Waterproof level: IP69K

With Removable Sunshade, Remote Control, U Shade metal bracket

Video Inputs: 2 way video input

OSD Language: English, Deutsch, French, Spanish, Portugal, Italia, Dutch

Connector: 4-PIN
